Professionals deserve in-demand features for excellent image quality. The Gendex Orthoralix 8500 delivers with the latest technology — such as the ease of laser beam positioning, the precision of morphology following, multi-motorized arm rotation, and the benefits of a 0.4 mm focal spot for exceptional detail recognition. Plus, with the option of a film-based or direct digital unit, there is a version of the 8500 to fit your needs for today and as your practice grows.
At last, a high quality, low maintenance panoramic is no longer a dream.
Gendex 8500 Installation Manual
Award-Winning Design- The Gendex Orthoralix 8500 sports an award-winning, modern design that links outstanding functionality and ease of use with pleasing high-tech aesthetics that simply look good in any practice. Integration into your office is a breeze. The small footprint and motorized telescopic column lets you place the 8500 where you need it — even when space is an issue.
- Medical Design Excellence Awards® recipient
- Motorized telescopic column makes the unit extremely compact
- Small footprint to fit into practices where space is an issue
Bookmark File PDF Gendex 8500 Installation Manual File Type Gendex 8500 Installation Manual File Type When people should go to the ebook stores, search creation by shop, shelf by shelf, it is essentially problematic. This is why we offer the books compilations in this website. The Orthoralix® 8500 DDE delivers panoramic focal detection, frontal and lateral TMJ imaging capabilities, plus a sleek new design with a small footprint. The system incorporates high-end features for detailed images, such as CCD sensor technology, articulated motion, constant focus and magnification, and 0.4 mm focal spot. Gendex Orthoralix 9000 User Manual - WordPress.com As this Gendex 8500 Installation Manual, it becomes one of the preferred Gendex 8500 Installation Manual book collections that we have. This is why you are in the right site to see the amazing books to own. It won't take more time to get this Gendex 8500 Installation Manual.
High End Technology- Once the patient is accurately positioned with the triple laser beam system, the Orthoralix 8500 uses multi-motorized arm rotation that allows the x-ray generator to maneuver in a sophisticated path thus producing a more precise reproduction of the entire dento-maxillo-facial region. Throughout the exposure, magnification is kept constant for minimal distortion in radiographs in both film-based and direct digital models.
- Simple laser beam positioning for accuracy
- Precise morphology following and multi-motorized arm rotation
- 0.4 mm focal spot for sharper images
Direct Digital Evolution- Featuring convenient built-in LAN connectivity, the Orthoralix 8500 DDE model hooks up to your network right out of the box without requiring a dedicated card to be installed into a PC. The panoramic film cassette is replaced by a CCD sensor that digitally captures the x-ray. This allows for instant access to images on any computer connected to the network in the practice, saving time and increasing efficiency and productivity.
- Replaces panoramic film cassette with the latest CCD sensor technology
- Built-in LAN connectivity eliminates the need for a dedicated PC to acquire images
- Access digital radiographs from any PC on the network to save time
Includes:
Gendex Orthoralix 8500 Dde Manual
- Acquisition computer included
| kV | 60 – 80 kV |
| mA | 4 – 10 mA |
| Focal Spot | 0.4 mm, IEC 60336 (1993) |
| Exposure Time | 11 s for the child pan, 12 s for the standard pan |
| Line Voltage | 115 V AC, 60 Hz or 250 V AC, 50 Hz |
| Maximum Line Power Rating | 10 A at 250 V, 15 A at 115 V |
| Weight | 254 lbs (115 kg) |
| CCD Sensor Resolution | 10.4 lp/mm |
| CCD Sensor Pixel Size | 48 ?m |
| CCD Sensor Active Area | 146 x 6 mm |
| Image Resolution | 5.2 lp/mm |
| Image Pixel Size | 96 ?m |
| Image Size | 1536 x 2725 pixels (Standard Pan) |
| Minimum PC Requirements | Pentium® II CPU, 400 MHz, 256 MB RAM |
| Required Operating System | Microsoft® Windows 98®/ Windows 2000®/ Windows XP® |
This unit MUST be plugged into a dedicated electrical circuit with breaker to insure consistent current.
